คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Adjustable Lever |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | NO/NC |
| IP Rating | IP67 |
| Maximum Current | 5 A |
| Housing Material | Die Cast Zinc Alloy, Thermoplastic |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Connection Type | Cable |
| Contact Type | Snap |
| Terminal Type | Wire Lead |
| Length | 31.5mm |
| Width | 158mm |
| Mechanical Life Minimum | 10000000 Operations |
| Standards Met | CE, CSA, RU, UL |
| Mounting Orientation | Vertical |
| Depth | 16mm |
| Minimum Operating Temperature | -25°C |
| Dimensions | 31.5 x 158 x 16 mm |
| Maximum Operating Temperature | +70°C |
| Operating Force | 0.08N |
