คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Actuator Type | Roller Plunger |
Pole and Throw Configuration | DPST |
Normal State Configuration | NO/NC |
IP Rating | IP66 |
Maximum Current | 10 A |
Housing Material | Plastic |
Maximum AC Voltage | 240V |
Maximum DC Voltage | 250V |
Connection Type | PG 11 |
Series | XCKT |
Contact Type | Snap Action |
Terminal Type | Screw |
Length | 58mm |
Width | 38mm |
Minimum Operating Temperature | -25°C |
Operating Force | 36N |
Mounting Orientation | Cable |
Depth | 51mm |
Dimensions | 58 x 38 x 51 mm |
Maximum Operating Temperature | +70°C |
Mechanical Life Minimum | 10000000 cycles |
