คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Roller Lever |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | 2NC/2NO |
| IP Rating | IP54 |
| Maximum Current | 3 A |
| Housing Material | Zinc Alloy |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Connection Type | PG 13.5 |
| Series | XCR |
| Contact Type | Snap Action |
| Terminal Type | Screw |
| Length | 85mm |
| Width | 75mm |
| Depth | 95mm |
| Operating Force | 0.75Nm |
| Maximum Operating Temperature | +70°C |
| Dimensions | 85 x 75 x 95 mm |
| Mechanical Life Minimum | 10000000 cycles |
| Minimum Operating Temperature | -25°C |
