คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Actuator Type | Roller Plunger |
Pole and Throw Configuration | SPDT |
Normal State Configuration | NC/NO |
IP Rating | IP00 |
Maximum Current | 20 A |
Maximum AC Voltage | 500V |
Maximum DC Voltage | 250V |
Connection Type | Screw |
Contact Type | Snap Action |
Terminal Type | Screw |
Length | 49.2mm |
Width | 17.45mm |
Minimum Operating Temperature | -25°C |
Depth | 25.5mm |
Dimensions | 49.2 x 17.45 x 25.5 mm |
Maximum Operating Temperature | +85°C |
Mechanical Life Minimum | 1000000 Operations |
Mounting Orientation | Panel, Side |
