คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V dc |
| Series | P2 |
| Maximum Switching Power DC | 60 W |
| Length | 14.5mm |
| Latching | No |
| Depth | 7.4mm |
| Height | 10.4mm |
| Dimensions | 14.5 x 10.4 x 7.2mm |
| Terminal Type | Surface Mount |
| Switching Current | 2A |
| Application | Communications Equipment, Consumer Electronics, HiFi, Line Card Applications, Measurement & Control Equipment, Medical Equipment, Office & Business Equipment, PABX, Set Top Boxes, Voice Over IP |
| Number of Poles | 2 |
| Maximum Operating Temperature | +85°C |
| Isolation Coil To Contact | 2kV rms |
| Relay Switching Classification | Non-Latching Relay |
| Minimum Operating Temperature | -40°C |
| Standards Met | cULus |
| Contact Material | Gold Plated |
| Features | Bifurcated Contacts, Immersion cleanable |
| Operating Temperature Range | -40 - +85°C |
| Coil Resistance | 64Ω |
| Maximum Switching Power AC | 62.5VA |
| Life | 100000000 (Mechanical) Operations, 50000000 (Electrical) Operations |
| Coil Power | 150mW |
