คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Minimum Input Voltage | 85V ac |
| Maximum Input Voltage | 264V ac |
| Output Voltage | 24 V dc |
| Minimum Output Voltage | 24V dc |
| Maximum Output Voltage | 28V dc |
| Output Current | 5 A |
| Power Rating | 120W |
| Number of Outputs | 1 |
| Width | 115mm |
| Allowed Circuit Configurations | Parallel, Series |
| Input Frequency Range | 47 → 63Hz |
| Series | DRF |
| Protection Features | Over Current Protection, Over Voltage Protection |
| Line Regulation | <96mV |
| Output Voltage Adjustment Range | 24 → 28V |
| Weight | 600g |
| Maximum Temperature | +70°C |
| Mounting Type | DIN Rail |
| Power Signal Conversion Type | AC-DC |
| Input Electrical Phase | Single Phase |
| Special Features | ErP Referenced Design, Remote On/Off, Remote Programming, Ultra Compact Footprint |
| Application | Cooler |
| Standards Met | ATEX, CE, CISPR22-B, EN 55022 Class B, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN/IEC/UL 60950-1, GL, IEC Ex, UL 508 |
| Holdup Time | 20ms |
| Ripple And Noise | <240mV |
| Maximum Input Current | 1.2 A, 600 mA |
| Hazardous Area Certification | ATEX |
| Minimum Temperature | -25°C |
