คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Power Rating | 0.75 kW, 1.5 kW |
Phase | 3 |
Supply Voltage | 380 → 480 V |
Current Rating | 1.7 A @ 380 V, 3 A @ 380 V |
Output Frequency | 0.1 → 599Hz |
For Use With | Synchronous Motors, Three Phase Asynchronous |
Ambient Temperature | -15 → +50 °C, +50 → +60 °C |
Overall Width | 206mm |
Overall Length | 144mm |
Overall Depth | 350mm |
Control Panel | Yes |
Drive Type | Variable Speed |
Field Bus Communication Type | CANOpen, DeviceNet, EtherCAT, Ethernet/IP, Modbus Serial, Modbus TCP, Profibus DP, Profinet |
Filter Included | Yes |
IP Rating | IP21 |
Standards Met | EN/IEC 61800-3, EN/IEC 61800-5-1, IEC 13849-1, IEC 60721-3, IEC 61000-3-12, IEC 61508, UL 508C |
Mounting Type | Wall Mount |
Series | ATV930 |
Function | Motor Control |
