คุณสมบัติ | รายละเอียด |
|---|---|
| Power Rating | 55 kW |
| Phase | 3 |
| Supply Voltage | 400 V ac |
| Current Rating | 106 A, 88 A |
| For Use With | Asynchronous Motors, Synchronous Motors |
| Series | ATV 630 |
| Field Bus Communication Type | Profibus |
| IP Rating | IP21 |
| Output Frequency | 0.1 → 500Hz |
| STO | Yes |
| Drive Type | Variable Frequency |
| Mounting Type | Panel Mount |
| Filter Included | Yes |
| Better World Claim | Saves energy |
| Better World Product | Yes |
| Better World Verification | Green Premium |
| Control Panel | Yes |
| Overall Length | 290mm |
| Special Features | 3 Qr Codes, Dynamic Predictive Maintenance, Energy Management (Integrated Power Measurement), Ethernet Port With Embedded Web Server, Simplified Communication |
| Function | Control Unit |
| Overall Depth | 323mm |
| Standards Met | EN/IEC 61800-3, EN/IEC 61800-3 Environment 1 Category C2, EN/IEC 61800-3 Environment 2 Category C3, EN/IEC 61800-5-1, IEC 60721-3, IEC 61000-3-12, IEC 61508, UL508C |
| Overall Width | 922mm |
| Interface | Ethernet, RS 485 |
