คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
| Power Rating | 11 kW |
| Phase | 3 |
| Supply Voltage | 400 V ac |
| Current Rating | 36.6 A |
| For Use With | Asynchronous Motors, Synchronous Motors |
| Series | ATV320 |
| Field Bus Communication Type | Profibus |
| IP Rating | IP20 |
| Output Frequency | 0.1 → 599Hz |
| STO | Yes |
| Drive Type | Variable Frequency |
| Mounting Type | DIN Rail |
| Filter Included | Yes |
| Control Panel | Yes |
| Special Features | Enhanced Automation Capabilities, Even at Low Speed & Dynamic Accuracy for Start/Stop Application, Open-Loop Motor Control Combined, Variable Speed Drive Improves Machine Effectiveness |
| Better World Product | Yes |
| Overall Depth | 330mm |
| Better World Verification | Green Premium |
| Overall Length | 180mm |
| Function | Motor Control |
| Standards Met | CE, CSA, cUL, EAC, EN 954-1, EN ISO 13849-1, EN ISO 13849-2, IEC 60204-1, IEC 6100, IEC 61158, IEC 61508, IEC 61784, IEC/EN 60721, NOM 117, RCM, UL |
| Overall Width | 232mm |
