คุณสมบัติ | รายละเอียด |
|---|---|
| Stepper Motor Type | Hybrid, Single Shaft |
| Step Angle | 1.8° |
| Holding Torque | 2.1Nm |
| Number Of Wires | 6 |
| Supply Voltage | 24 V |
| Frame Size | 60 x 60mm |
| Shaft Diameter | 8mm |
| Current Rating | 3 A |
| Winding Arrangement | Unipolar |
| Shaft Length | 20.6mm |
| Depth | 87.3mm |
| Resistance Per Phase | 1.25Ω |
| Series | 103H7 |
| Standards Met | CE, UL, TUV, RoHS Compliant |
SM2562C20B41
SM2863-5151
