คุณสมบัติ | รายละเอียด |
|---|---|
| Stepper Motor Type | Hybrid, Single Shaft |
| Step Angle | 1.8° |
| Holding Torque | 0.30Nm |
| Number Of Wires | 6 |
| Supply Voltage | 24 V |
| Frame Size | 42 x 42mm |
| Shaft Diameter | 5mm |
| Current Rating | 1.2 A |
| Winding Arrangement | Unipolar |
| Shaft Length | 24mm |
| Depth | 40.5mm |
| Resistance Per Phase | 2.9Ω |
| Series | 103H5 |
| Maximum Output Torque | 0.3 Nm |
| Standards Met | CE, UL, TUV, RoHS Compliant |
SM2862-5151
103H7123-0440
