Attribute | Value |
---|---|
Supply Voltage | 24 → 240 V ac/dc |
Time Range | 0.1 → 20 min, 0.1 → 20 s, 0.1 → 24 h |
Mode of Operation | ON Delay |
Mounting Type | DIN Rail |
Number of Timer Functions | Single |
Number of Contacts | 1 |
Series | 80 Series |
Time Increment | Hours, Minutes, Seconds |
Power Supply | External |
Contact Configuration | SPDT |
Current Maximum | 16 A |
Terminal Type | Screw |
Minimum Voltage | 16.8 V ac/dc |
Maximum Voltage | 265 V ac/dc |
Depth | 60.8mm |
Maximum Operating Temperature | +50°C |
Switch Configuration | SPDT |
Length | 84mm |
Width | 17.5mm |
Minimum Operating Temperature | -10°C |
CAD Drawing | 3D CAD Model |
Contact Material | Silver Cadmium Oxide |
Time Delay | 100 ms |
