| Attribute | Value |
|---|---|
| Supply Voltage | 100 → 120 V ac |
| Time Range | 0.1 s → 10 min |
| Mode of Operation | Flicker OFF Start, Flicker ON Start, Interval, ON Delay |
| Mounting Type | DIN Rail, Flush Mount |
| Number of Timer Functions | Multi Function |
| Number of Contacts | 2 |
| Series | H3YN |
| Time Increment | Minutes, Seconds |
| Power Supply | External |
| Current Maximum | 5 A |
| Terminal Type | Socket |
| Maximum Voltage | 250 V ac |
| Depth | 63mm |
| Maximum Operating Temperature | +50°C |
| CAD Drawing | 3D CAD Model |
| Minimum Operating Temperature | -10°C |
| Time Delay | 0.1 s |
| Length | 28mm |
| Switch Configuration | DPDT |
| Width | 21.5mm |
