คุณสมบัติ | รายละเอียด |
|---|---|
| Power Rating | 18.5 kW |
| Phase | 3 |
| Supply Voltage | 400 V ac |
| Current Rating | 39 A |
| For Use With | Conveyor Belt Systems, Fan Application, Pump |
| Field Bus Communication Type | CANOpen |
| IP Rating | IP20 |
| Output Frequency | 0 - 50Hz |
| STO | No |
| Drive Type | Vector Control |
| Mounting Type | Flange Mount |
| Filter Included | Yes |
| Special Features | Control of High Efficient IE4 Motors, DC Braking, Detachable Control Signal Terminal Strip, Fast Commissioning with 14 Basic Parameters, Full Short Circuit Protection, Integrated Braking Transistor, Integrated Canopen & Modbus RTU, Integrated EMC Filter, Integrated PI Controller, Large Overload Capability, Sensorless Vector Control, V/F Control, Voltage Boost |
| Overall Width | 211mm |
| Standards Met | CE, cUL, EAC, RCM, UkrSEPRO, UL |
| Overall Depth | 418.5mm |
| Overall Length | 173mm |
| Function | Motor Control |
6SL3210-1PE12-3UL1
EFC5610-0K75-3P4-MDA-7P-NNNNN-L1NN
6SL3244-0BB12-1BA1
6SL3210-1KE21-3AF1
FR-F840-00126-E2-60
6SL3210-1KE26-0AF1
