คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Monitoring Application | Phase, Voltage |
Supply Voltage | 280 → 520 V ac |
Contact Configuration | SPDT |
Voltage Sensitivity | Undervoltage |
Voltage Sensing Range | Maximum of 520 V |
Phase Sensitivity | Phase Failure |
Time Delay | 100 ms |
Length | 66.5mm |
Mounting Type | DIN Rail |
Operating Temperature Range | -20 → +60 °C |
Maximum Operating Temperature | +60°C |
Series | L-Series |
Current Range | Maximum of 8 A |
Standards Met | IEC 60664 |
Special Features | Time Delay |
Minimum Operating Temperature | -20°C |
Height | 89mm |
Terminal Type | Screw |
Width | 17.5mm |
Dimensions | 17.5 x 89 x 66.5 mm |
