คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Monitoring Application | Voltage |
Supply Voltage | 8 → 30 V dc |
Contact Configuration | SPDT |
Voltage Sensitivity | Undervoltage |
Voltage Sensing Range | 12 → 24 V dc |
Time Delay | 0 → 30 s |
Series | L-Series |
Terminal Type | Screw |
Width | 17.5mm |
Length | 66.5mm |
Mounting Type | DIN Rail |
Operating Temperature Range | -20 → +60 °C |
Height | 89mm |
Current Range | Maximum of 8 A |
Standards Met | IEC 60664 |
Dimensions | 17.5 x 89 x 66.5 mm |
