คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Power Rating | 2.2 kW |
Phase | 1 |
Supply Voltage | 200 → 240 V |
Current Rating | 9.8 A |
Output Frequency | 0 → 600Hz |
For Use With | 2.2 kW AC Motor |
Ambient Temperature | -10 → +40°C |
Overall Width | 105mm |
Overall Length | 239mm |
Overall Depth | 191mm |
Control Panel | No |
Drive Type | Vector Control |
Filter Included | Yes |
Standards Met | C-Tick, CE, CUL, EMC Directive 2004/108/EC, Environmental System ISO 14001, GOST R, Low Voltage Directive 2006/95/EC, Machinery Directive 2006/42/EC, Quality Assurance System ISO 9001, UL |
Special Features | Flash Drop Tool, Programmable Control Connection, Safe Torque-Off Function, Sequence Programming, Serial and Ethernet Communication, Speed Compensated Stop |
Series | ACS355 |
Mounting Type | Cabinet, DIN Rail |
IP Rating | IP20 |
Function | Motor Control |
