คุณสมบัติ | รายละเอียด |
|---|---|
| Pressure Reading Type | Relative |
| Minimum Pressure Reading | 0bar |
| Maximum Pressure Reading | 400bar |
| Accuracy | ±0.5 % |
| Output Type | 2x PNP/NPN-NO/NC |
| Media Measured | Fluid |
| Process Connection | G1/4 |
| Electrical Connection | M12 Connector |
| Communication Protocol | IO-LINK |
| Response Time | <3 (Minimum Switching Output) ms |
| Maximum Current | 150 mA @ +60 °C, 200 mA @ +60 °C, 250 mA @ +40 °C |
| Supply Voltage | 18 → 30 V dc |
| Interface | IO-Link |
| Housing Material | PBT GF20, PBT+PC GF30, PC, Stainless Steel |
| Minimum Operating Temperature | -25°C |
| IP Rating | IP65, IP67 |
| Maximum Operating Temperature | +80°C |
PMP21-AA1U2PBWJJ
3100R0040G01B000
PBS2-CB1X0SG2SS0LMA0Z
54D-P016G-DA1-AA
