คุณสมบัติ | รายละเอียด |
|---|---|
| Pressure Reading Type | Relative |
| Minimum Pressure Reading | 0bar |
| Maximum Pressure Reading | 250bar |
| Accuracy | ±0.5 % |
| Output Type | Analogue + PNP-NO/NC Programmable |
| Media Measured | Fluid |
| Process Connection | G1/4 |
| Electrical Connection | M12 Connector |
| Analogue Output | 0 → 10 V |
| Communication Protocol | IO-LINK |
| Response Time | <3 (Maximum Analogue Output) ms, <3 (Minimum Switching Output) ms |
| Maximum Current | 150 mA @ +60 °C, 200 mA @ +60 °C, 250 mA @ +40 °C |
| Supply Voltage | 18 → 30 V dc |
| Interface | IO-Link |
| Housing Material | PBT GF20, PBT+PC GF30, PC, Stainless Steel |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -25°C |
| IP Rating | IP65, IP67 |
KE1-6-M-B05C-1-4-D-S 2130X000X00
PMP23-AA1M1FBWSJ
NPA-300B-015A
M32-6-M-B35D-1-4-D 2130X000X00
