รายละเอียดสินค้า / Product Details
| คุณสมบัติ | Value |
|---|---|
| Output Type | PNP |
| Body Style | Barrel |
| Mounting Style | Cable Mount |
| Supply Voltage | 10 → 30 V dc |
| Terminal Type | M12 Connector |
| Maximum DC Voltage | 30V |
| Detection Range | 1.7 mm |
| Switching Current | 50 mA |
| Switching Frequency | 15 kHz |
| Width | 15 (Dia.)mm |
| Depth | 60mm |
| Dimensions | 15 (Dia.) x 60 mm |
| Short Circuit Overload Protection | Yes |
| Housing Material | Brass (Socket), FPM (O-Ring), Polyamide |
| IP Rating | IP65, IP68, IP69K |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -32°C |
| Reverse Polarity Protection | Yes |
