คุณสมบัติ / Specifications
| คุณสมบัติ | Value |
|---|---|
| Output Voltage | 48V dc |
| Input Voltage Range | 9 → 36 V dc |
| Input Voltage Nominal | 24 V dc |
| Isolation Voltage | 2.5kV dc |
| Power Rating | 20W |
| Output Current | 420mA |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Package | Encapsulated |
| Efficiency | 89% |
| Minimum Temperature | -40°C |
| Maximum Temperature | +85°C |
| Load Regulation | 1% |
| Line Regulation | ±0.5% |
| Power Signal Conversion Type | DC-DC |
| Series | DTE20 |
| MTBF | 750kh |
| Protection Features | Over Voltage Protection, Overload Protection, Short Circuit Protection |
| Maximum Input Current | 70 (No Load) mA, 940 (Full Load) mA |
| Depth | 23.3mm |
| Width | 54mm |
| Ripple And Noise | 200mV Pk-Pk |
| Length | 96mm |
| Weight | 107g |
