คุณสมบัติ | รายละเอียด |
|---|---|
| Sensor Technology | Inductive |
| Detection Range | 5 mm |
| Body Style | Block |
| Output Function | NO |
| Digital Switching Output Type | 2-Wire |
| Cable Length | 2m |
| Connection Type | Pre-Cabled |
| Supply Voltage | 12 → 24 V dc |
| Length | 15mm |
| IP Rating | IP68 |
| Mounting Type | Flush |
| Width | 8mm |
| Housing Material | PPS |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -25°C |
| Switching Frequency | 5 kHz |
| Maximum Operating Temperature | +70°C |
| Reverse Polarity Protection | Yes |
| Series | OsiSense XS |
| Maximum Switching Frequency | 5kHz |
| Shielding | Unshielded |
| Switching Current | 100 mA |
| Depth | 32mm |
| Short Circuit Overload Protection | Yes |
