คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Sensor Technology | Inductive |
| Thread Size | M30 x 1.5 |
| Body Style | Barrel |
| Detection Range | 15 mm |
| Terminal Type | M12 - 4 Pin |
| Supply Voltage | 10 → 58 V dc, 12 → 48 V dc |
| Length | 61.9mm |
| Maximum DC Voltage | 48 V, 58V |
| Mounting Type | Non Flush |
| IP Rating | IP67 |
| Switching Current | 200 mA |
| Housing Material | PPS |
| Minimum Operating Temperature | -25°C |
| Standards Met | CCC, CE, CSA, UL |
| Reverse Polarity Protection | Yes |
| Short Circuit Overload Protection | Yes |
| Maximum Operating Temperature | +70°C |
| Maximum Switching Frequency | 1000Hz |
