คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Sensor Technology | Inductive |
Body Style | Barrel |
Thread Size | M30 x 1.5 |
Output Type | NPN |
Detection Range | 15 mm |
Terminal Type | M12 - 4 Pin |
Supply Voltage | 12 → 24 V dc |
Length | 68mm |
Maximum DC Voltage | 24V |
Mounting Type | Non Flush |
Switching Current | 200 mA |
IP Rating | IP65, IP67 |
Housing Material | Brass Nickel Plated |
Minimum Operating Temperature | -25°C |
Reverse Polarity Protection | Yes |
Maximum Switching Frequency | 300Hz |
Shielding | Partial |
Maximum Operating Temperature | +70°C |
Standards Met | CE, CSA, IEC 60068-2-27, IEC 60068-2-6, IEC 60529, UL |
Short Circuit Overload Protection | Yes |
