คุณสมบัติ | รายละเอียด |
|---|---|
| Thread Size | M8 |
| Sensor Technology | Inductive |
| Detection Range | 2.5 mm |
| Body Style | Barrel |
| Output Function | NC |
| Digital Switching Output Type | PNP |
| Connection Type | Pre-Cabled |
| Cable Length | 2m |
| Supply Voltage | 10 → 36 V dc, 12 → 24 V dc |
| Length | 33.2mm |
| IP Rating | IP65, IP67 |
| Mounting Type | Flush |
| Housing Material | Brass Nickel Plated |
| Maximum DC Voltage | 36V |
| Minimum Operating Temperature | -25°C |
| Short Circuit Overload Protection | Yes |
| Series | General Purpose |
| Standards Met | CE, CSA, UL |
| Switching Frequency | 2.5 kHz |
| Maximum Operating Temperature | +70°C |
| Reverse Polarity Protection | Yes |
| Switching Current | 200 mA |
| Maximum Switching Frequency | 2.5kHz |
| Shielding | Shielded |
| Depth | 13mm |
IQ20-07BNSDP0S
BES 516-3005-G-E4-C-PU-02
IME18-08BNSZW5S
IM30-15NUO-ZU0
IME12-10NPOZW2K
CA18EAN12BPM1IO
IME12-04BPSZW2S
