คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Connection Type | M16 |
| Lock Style | Key |
| Normal State Configuration | 3NC |
| Housing Material | Glass Fibre Reinforced PA |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Safety Contacts | 3NC |
| Range | Preventa |
| Actuator Included | Yes |
| Number of Head Directions | 8 |
| Series | XCSTA |
| IP Rating | IP67 |
| Depth | 115mm |
| Minimum Operating Temperature | -25°C |
| Length | 52mm |
| Width | 30mm |
| Dimensions | 52 x 30 x 115 mm |
| Maximum Operating Temperature | +70°C |
| Standards Met | CSA, CSA C22.2 No. 14, EN 1088, EN/IEC 60204-1, EN/IEC 60947-5-1, EN/ISO 12100, ISO 14119, TC, UL, UL 508 |
| Maximum Current | 6 A |
