คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Roller Lever |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | 1NC/1NO |
| IP Rating | IP66, IP67 |
| Maximum Current | 10 A |
| Housing Material | Plastic |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Connection Type | PG 11 |
| Series | XCKP |
| Contact Type | Snap Action |
| Terminal Type | Screw |
| Length | 31mm |
| Width | 30mm |
| Mounting Orientation | Cable |
| Operating Force | 18N |
| Depth | 65mm |
| Minimum Operating Temperature | -25°C |
| Maximum Operating Temperature | +70°C |
| Dimensions | 31 x 30 x 65 mm |
| Mechanical Life Minimum | 15000000 cycles |
