คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Coil Spring |
| Pole and Throw Configuration | DP |
| Normal State Configuration | NO/NC |
| IP Rating | IP66, IP67 |
| Maximum Current | 10 A |
| Housing Material | Plastic |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Series | OsiSense XC |
| Contact Type | Snap Action |
| Terminal Type | Screw |
| Length | 65mm |
| Width | 31mm |
| Maximum Operating Temperature | +70°C |
| Mounting Orientation | Multi Directional |
| Mechanical Life Minimum | 5000000 cycles |
| CAD Drawing | 3D CAD Model |
| Depth | 30mm |
| Minimum Operating Temperature | -25°C |
| Dimensions | 65 x 31 x 30 mm |
