คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Lever |
| Pole and Throw Configuration | 4PST |
| Normal State Configuration | 2NC |
| IP Rating | IP66 |
| Maximum Current | 10 A |
| Housing Material | Zamak |
| Maximum AC Voltage | 240V |
| Maximum DC Voltage | 250V |
| Connection Type | M20 |
| Series | XCKMR |
| Contact Type | Slow Break |
| Terminal Type | Screw |
| Length | 200mm |
| Width | 59mm |
| Dimensions | 200 x 59 x 118 mm |
| Mechanical Life Minimum | 2000000 cycles |
| Minimum Operating Temperature | -25°C |
| Operating Force | 0.75Nm |
| Depth | 118mm |
| Maximum Operating Temperature | +70°C |
