คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 3V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 220V dc |
| Series | Axicom |
| Maximum Switching Power DC | 60 W |
| Length | 10mm |
| Latching | Yes |
| Depth | 6mm |
| Height | 5.65mm |
| Dimensions | 10 x 5.65 x 6mm |
| Terminal Type | Through Hole |
| Switching Current | 2A |
| Application | Automotive, Telecommunications |
| Number of Poles | 2 |
| Isolation Coil To Contact | 1.8kV rms |
| Coil Power | 100mW |
| Minimum Operating Temperature | -40°C |
| Contact Material | Gold Plated |
| Maximum Operating Temperature | +85°C |
| Maximum Switching Power AC | 62.5VA |
| Operating Temperature Range | -40 - +85°C |
| Coil Resistance | 90Ω |
| Life | 100000000 (Mechanical) cycles |
