คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Minimum Input Voltage | 90 V ac, 120 V dc |
| Input Voltage | 230V ac |
| Maximum Input Voltage | 264 V ac, 370 V dc |
| Output Voltage | Maximum of 15 V dc |
| Maximum Output Voltage | 15V dc |
| Output Current | 2 A |
| Power Rating | 30W |
| Number of Outputs | 1 |
| Electrical Phase | 1 |
| Type | Switch Mode |
| Dimensions | 53 x 55.6 x 91mm |
| Height | 91mm |
| Width | 53mm |
| Load Regulation | 1 |
| Application | Industrial |
| Minimum Temperature | -25°C |
| Ripple And Noise | 50mV |
| Input Frequency Range | 47 → 63Hz |
| Line Regulation | 1% |
| Series | DSP |
| Power Signal Conversion Type | AC/DC-DC |
| Mounting Type | DIN Rail |
| Input Electrical Phase | 1 |
| Maximum Temperature | +71°C |
| Weight | 200g |
| Depth | 55.6mm |
| Maximum Input Current | 800mA |
| Protection Features | Over Current Protection, Over Voltage Protection |
| Holdup Time | 25ms |
| Standards Met | CE, EN 55022, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, IEC 60068-2-27, IEC 60068-2-6, UL 1310 Class 2, UL 508, UL 60950-1, UL 94 V-0 |
| Output Voltage Adjustment Range | 13.5 → 16.5V |
