| Attribute | Value |
|---|---|
| Supply Voltage | 12 → 240 V ac/dc |
| Time Range | 0.05 → 100 s, 3 → 100 min, 5 → 100 h |
| Mode of Operation | Additive ON Delay with Auxiliary Voltage, Flash Start with Interval, OFF Delay with Auxiliary Voltage, ON Delay, Passing Break Contact with Auxiliary Voltage, Passing Make Contact, Pulse Former with Auxiliary Voltage |
| Mounting Type | DIN Rail |
| Number of Timer Functions | Multi Function |
| Number of Contacts | 1 |
| Time Increment | Hours, Minutes, Seconds |
| Power Supply | External |
| Contact Configuration | SPDT |
| Current Maximum | 1 (dc) A, 3 (ac) A |
| Terminal Type | Screw |
| Maximum Voltage | 250 V ac/dc |
| Switch Configuration | SPDT |
| Length | 90mm |
| Width | 17.5mm |
| Depth | 66.7mm |
| Maximum Operating Temperature | +55°C |
| Minimum Operating Temperature | -25°C |
