คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Monitoring Application | Voltage |
| Supply Voltage | 17 → 275 V ac/dc |
| Contact Configuration | SPDT |
| Voltage Sensitivity | Overvoltage, Undervoltage |
| Voltage Sensing Range | 17 → 275 V ac/dc |
| Time Delay | 0.1 → 20 s |
| Maximum Voltage Sensed | 275V ac/dc |
| CAD Drawing | 3D CAD Model |
| Minimum Voltage Sensed | 17 V ac/dc |
| Minimum Operating Temperature | -25°C |
| Width | 23mm |
| Dimensions | 91 x 23 x 92 mm |
| Length | 91mm |
| Operating Temperature Range | -25 → +60 °C |
| Maximum Operating Temperature | +60°C |
| Height | 92mm |
