คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
---|---|
Monitoring Application | Current |
Supply Voltage | 24 → 240 V ac/dc |
Contact Configuration | SPDT |
Electrical Phase | 1 |
Current Sensitivity | Overcurrent, Undercurrent |
Minimum Current Sensed | 50mA |
Maximum Current Sensed | 10A |
Time Delay | 0.1 → 20 s |
Current Range | 0.05 → 10 A |
CAD Drawing | 3D CAD Model |
Width | 22.5mm |
Height | 92mm |
Length | 91mm |
Dimensions | 91 x 22.5 x 92 mm |
