คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 50 A |
| Mounting Type | DIN Rail |
| Maximum Load Voltage | 230 V |
| Minimum Load Voltage | 24 V |
| Minimum Control Voltage | 15 V dc |
| Maximum Control Voltage | 24 V dc |
| Switching Type | Zero Crossing |
| Control Voltage Range | 15 → 24 V dc |
| Range | SIRIUS 3RF |
| Minimum Load Current | 0.5 A |
| Contact Configuration | SPST |
| Terminal Type | Screw |
| Output Device | Thyristor |
| Load Voltage Range | 24 → 230V |
| Series | 3RF2 |
| Maximum Turn On Time | 1 (+1/2 cycle) ms |
| Dimensions | 67.5 x 156 x 100mm |
| Depth | 156mm |
| Minimum Operating Temperature | -25°C |
| Length | 67.5mm |
| Operating Temperature Range | -25 → +60°C |
| Maximum Operating Temperature | +60°C |
| Height | 100mm |
| Off State Leakage Current | 10 mA |
