คุณสมบัติ | รายละเอียด |
|---|---|
| Series | YG2A25 |
| Number of Cores | 5 |
| Cross Sectional Area | 0.34 mm² |
| Sheath Colour | Black |
| Length | 10m |
| Sheath Material | Polyurethane PUR |
| Connector 1 | M12 |
| Connector 1 Gender | Female |
| Connector 1 Orientation | Straight |
| Connector 1 Number of Contacts | 5 |
| Connector 2 Orientation | Straight |
| Connector 2 | Unterminated |
| Coding | A |
| Shielding | Shielded |
| Shielded/Unshielded | Shielded |
| Voltage Rating | 60 V ac/dc |
| Current Rating | 4 A |
| IP Rating | IP65, IP66K, IP67 |
| Maximum Operating Temperature | +80°C |
| Standards Met | CE |
| Minimum Bend Radius | 56 mm |
| Minimum Operating Temperature | -25°C |
| Outer Diameter | 5.6mm |
| American Wire Gauge | 22 AWG |
| Operating Temperature Range | -25 - 80 °C |
| Connector 1 Housing Gender | Female |
BCC M425-0000-1A-003-VX8434-050
40212 RKWT 5-228/2 M
NEBB-M12G5-P-2.5-LE3
28382 RKMWV 4-225/2 M
V1-WV4A-10M-PP-H1
M12A-17BMMM-PL8B01
