คุณสมบัติ | รายละเอียด |
|---|---|
| Series | YF2A28 |
| Number of Cores | 8 |
| Cross Sectional Area | 0.25 mm² |
| Length | 10m |
| Sheath Colour | Black |
| Sheath Material | Polyvinyl Chloride PVC |
| Connector 1 | M12 |
| Connector 1 Gender | Female |
| Connector 1 Number of Contacts | 8 |
| Connector 1 Orientation | Straight |
| Connector 2 | Unterminated |
| Coding | A |
| Shielding | Shielded |
| Shielded/Unshielded | Shielded |
| Voltage Rating | 30 V ac/dc |
| Current Rating | 2 A |
| IP Rating | IP65, IP66K, IP67 |
| Minimum Bend Radius | 70 mm |
| Minimum Operating Temperature | -5°C |
| Maximum Operating Temperature | +80°C |
| American Wire Gauge | 24 AWG |
| Operating Temperature Range | -5 - 80 °C |
| Outer Diameter | 7mm |
| Connector 1 Housing Gender | Female |
