คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
Sensor Style | Block |
Detection Type | Background Suppression |
Detection Range | 10 mm → 1 m |
Output Type | NPN/PNP |
Electrical Connection | M12 Connector |
Maximum DC Voltage | 30V |
Terminal Type | M12 4 Pin Connector |
Light Source | LED |
IP Rating | IP66, IP67 |
Maximum Current | 100 mA |
Response Time | <500 μs |
Housing Material | Plastic, Vistal |
Standards Met | CE Certified, cULus Recognized, UL NRKH.E181493, UL NRKH7.E181493 |
Series | W16 |
Mounting Type | Panel Mount |
Minimum Operating Temperature | -40°C |
Maximum Operating Temperature | +60°C |
