คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 160 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 72 V dc |
| Minimum Load Voltage | 7 V dc |
| Minimum Control Voltage | 4.5 V dc |
| Maximum Control Voltage | 32 V dc |
| Switching Type | DC |
| Control Voltage Range | 4.5 → 32 V dc |
| Minimum Load Current | 2.5 mA |
| Terminal Type | Quick Connect |
| Relay Type | Solid State Relay |
| Maximum Turn On Time | 8.5 μs, 90.5 μs |
| Series | HDC |
| Load Voltage Range | 7 → 72V dc |
| Dimensions | 104 x 20.1 x 73.5mm |
| Height | 73.5mm |
| Depth | 20.1mm |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -30°C |
| Special Features | LED Status Indicator, Heavy Duty Stud Terminals |
| Operating Temperature Range | -30 → +80°C |
| Off State Leakage Current | 0.15 mA |
| Length | 104mm |
