คุณสมบัติ | รายละเอียด |
|---|---|
| Current Rating | 10A |
| Number of Poles | 1 |
| Voltage Rating | 240V |
| Series | T9-311 |
| Application | Household Appliances, HVAC, Industrial Appliances, Medical, Power Supplies, Power Tools, Uninterruptible Power Supply |
| Tripping Mechanism | Thermal |
| Reset Actuator Type | Button |
| Mounting Style | Snap In |
| Mounting Hole Size | 8.9 x 9.6 (Dia.)mm |
| Rated DC Voltage | 48/32V |
| Mounting Hole Diameter | 9.6mm |
| Overall Length | 19mm |
| Terminal Contact Type | Quick Connect |
| Overall Depth | 51.5mm |
| Overall Dimensions | 19 x 19 x 51.5mm |
| Breaking Capacity at Maximum Voltage Rating | 2 kA |
| Circuit Breaker Type | Thermal Magnetic Circuit Breaker |
