คุณสมบัติ | รายละเอียด |
|---|---|
| Maximum Load Current | 25 A |
| Mounting Type | Panel Mount |
| Maximum Load Voltage | 150 V dc |
| Minimum Load Voltage | 1 V dc |
| Maximum Control Voltage | 32 V dc |
| Minimum Control Voltage | 3.5 V dc |
| Switching Type | DC |
| Control Voltage Range | 3.5 - 32 V dc |
| Minimum Load Current | 0 A |
| Range | Harmony Solid State Relays |
| Number of Poles | 1 |
| Contact Configuration | SPST |
| Terminal Type | Screw |
| Output Device | MOSFET |
| Relay Type | Solid State Relay |
| Maximum Turn On Time | 0.1ms |
| Series | Harmony Relay |
| Load Voltage Range | 1 - 150V dc |
| Better World Product | Yes |
| Better World Verification | Green Premium |
| Dimensions | 44.45 x 34.29 x 58.89mm |
| Capacitance | 50pF |
| Special Features | Green LED for Input Visualization |
| Operating Temperature Range | -40 - +80°C |
| Maximum Operating Temperature | +80°C |
| Minimum Operating Temperature | -40°C |
| Standards Met | CE, CSA, EAC, EN/IEC, REACH, UL |
| Height | 58.9mm |
| Off State Leakage Current | <= 0.3 mA |
| Length | 44.5mm |
| Depth | 34.3mm |
