Attribute | Value |
---|---|
Supply Voltage | 24 → 240 V ac/dc |
Time Range | 0.3 → 300 s |
Mode of Operation | OFF Delay |
Mounting Type | DIN Rail |
Number of Timer Functions | Single |
Number of Contacts | 2 |
Series | RE22 R2 |
Time Increment | Seconds |
Power Supply | External |
Contact Configuration | DPDT |
Current Maximum | 5 A |
Terminal Type | Screw |
Minimum Voltage | 24 V ac/dc |
Maximum Voltage | 240 V ac/dc |
Minimum Operating Temperature | -20°C |
Time Delay | <100 ms |
Switch Configuration | DPCO |
Length | 22.9mm |
Width | 90mm |
Depth | 79.5mm |
Maximum Operating Temperature | +60°C |
