| Attribute | Value |
|---|---|
| Supply Voltage | 24 → 240 V ac/dc |
| Time Range | 0.3 → 300 s |
| Mode of Operation | OFF Delay |
| Mounting Type | DIN Rail |
| Number of Timer Functions | Single |
| Number of Contacts | 1 |
| Series | RE22 R1 |
| Time Increment | Seconds |
| Power Supply | External |
| Contact Configuration | SPDT |
| Current Maximum | 5 A |
| Terminal Type | Screw |
| Minimum Voltage | 24 V ac/dc |
| Maximum Voltage | 240 V ac/dc |
| Length | 22.9mm |
| Width | 90mm |
| Switch Configuration | SPCO |
| Maximum Operating Temperature | +60°C |
| Minimum Operating Temperature | -20°C |
| Depth | 79.5mm |
| Time Delay | <100 ms |
