คุณสมบัติ / Specifications
คุณสมบัติ | รายละเอียด |
Power Rating | 15 kW |
Phase | 3 |
Supply Voltage | 500 V |
Current Rating | 47.3 A |
Series | ATV320 |
For Use With | Asynchronous Motors, Synchronous Motors |
Field Bus Communication Type | Profibus |
IP Rating | IP20 |
Output Frequency | 0.1 → 599Hz |
STO | Yes |
Drive Type | Variable Frequency |
Mounting Type | DIN Rail |
Filter Included | Yes |
Control Panel | Yes |
Function | Motor Control |
Better World Verification | Green Premium |
Overall Depth | 232mm |
Better World Product | Yes |
Hazardous Area Certification | ATEX |
Standards Met | CE, CSA, cUL, EAC, EN 954-1, EN ISO 13849-1, EN ISO 13849-2, IEC 60204-1, IEC 6100, IEC 61158, IEC 61508, IEC 61784, IEC/EN 60721, NOM 117, RCM, UL |
Overall Width | 180mm |
Overall Length | 404mm |
Special Features | Enhanced Automation Capabilities, Even at Low Speed & Dynamic Accuracy for Start/Stop Application, Open-Loop Motor Control Combined, Variable Speed Drive Improves Machine Effectiveness |
