คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Actuator Type | Roller Lever |
| Pole and Throw Configuration | DPST |
| Normal State Configuration | NO/NC |
| IP Rating | IP66 |
| Maximum Current | 10 A |
| Housing Material | Zinc Alloy |
| Maximum AC Voltage | 400V |
| Maximum DC Voltage | 250V |
| Connection Type | Cable |
| Contact Type | Snap |
| Terminal Type | Screw |
| Length | 30.3mm |
| Width | 94mm |
| Minimum Operating Temperature | -25°C |
| Depth | 32.5mm |
| Dimensions | 30.3 x 94 x 32.5 mm |
| Maximum Operating Temperature | +70°C |
| Operating Force | 7N |
| Mechanical Life Minimum | 15000000 Operations |
| Mounting Orientation | Vertical |
| Standards Met | CE, CSA, RU, UL |
