คุณสมบัติ / Specifications
| คุณสมบัติ | รายละเอียด |
|---|---|
| Body Style | Barrel |
| Thread Size | M12 x 1 |
| Output Type | NPN-NO |
| Detection Range | 2 mm |
| Terminal Type | M12 - 4 Pin |
| Supply Voltage | 10 → 30 V dc |
| Length | 65mm |
| Maximum DC Voltage | 30V |
| Mounting Type | Flush Mount |
| IP Rating | IP67 |
| Switching Current | 150 mA |
| Housing Material | Nickel Plated Brass |
| Reverse Polarity Protection | Yes |
| Maximum Switching Frequency | 2kHz |
| Maximum Operating Temperature | +75°C |
| Short Circuit Overload Protection | Yes |
| Standards Met | CULus Listed, EN 60947-5-2, RoHS Compliant, UL |
| Minimum Operating Temperature | -25°C |
