คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 2 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Series | Axicom P2 |
| Maximum Switching Power DC | 60 W |
| Latching | No |
| Length | 10mm |
| Depth | 6.5mm |
| Height | 5.65mm |
| Dimensions | 10 x 5.65 x 6.5mm |
| Terminal Type | Through Hole |
| Switching Current | 2A |
| Number of Poles | 2 |
| Application | Signal |
| Operating Temperature Range | -40 - +85°C |
| Coil Resistance | 2800Ω |
| Maximum Switching Power AC | 62.5VA |
| Coil Power | 200mW |
| Life | 100000 (Electrical) Operations, 100000000 (Mechanical) Operations |
| Isolation Coil To Contact | 1.6kV ac |
| Features | High Contact Capacity, Low Power Consumption |
| Relay Switching Classification | Subminiature Signal Relay |
| Standards Met | cULus E133481, RoHS Compliant |
| Contact Material | Gold Plated |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +85°C |
| Electrical Life | 10^5 Operations |
