คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Switching Current | 8A |
| Number of Poles | 2 |
| Latching | No |
| Terminal Type | Through Hole |
| Maximum Switching Voltage AC | 440V ac |
| Maximum Switching Voltage DC | 300V dc |
| Length | 29mm |
| Coil Resistance | 1.44 kΩ |
| Coil Power | 400mW |
| Life | 100000 (Electrical) cycles, 10000000 (Mechanical) cycles |
| Contact Material | Silver Alloy |
| Height | 15.7mm |
| Isolation Coil To Contact | 5kV ac |
| Maximum Operating Temperature | +85°C |
| Standards Met | CQC 02001001951, RoHS Compliant, UL E134517, VDE 116934 |
| Minimum Operating Temperature | -40°C |
| Depth | 12.7mm |
| Maximum Switching Power AC | 2 kVA |
| Application | Power |
PCFN-112H2MG
55.34.8.110.0040
46.52.8.024.0040
TXS2-4.5V-1
T92P7A22-24 6-1393211-0
HF41F-024-ZS
