คุณสมบัติ | รายละเอียด |
|---|---|
| Coil Voltage | 5V |
| Contact Configuration | SPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 3 A |
| Maximum Switching Current DC | 3 A |
| Maximum Switching Voltage AC | 250V ac |
| Maximum Switching Voltage DC | 220V dc |
| Series | DS |
| Maximum Switching Power DC | 60 W |
| Length | 15mm |
| Latching | No |
| Depth | 9.9mm |
| Height | 9.9mm |
| Terminal Type | Through Hole |
| Number of Poles | 2 |
| Switching Current | 3A |
| Coil Resistance | 1440Ω |
| Coil Power | 400mW |
| Isolation Coil To Contact | 1.5kV rms |
| Maximum Switching Power AC | 125VA |
| Minimum Operating Temperature | -40°C |
| Maximum Operating Temperature | +70°C |
| Contact Material | Gold Plated |
G6KU-2F-Y DC5
HFD2/005-S-L1-D
G6AK-274P-ST-US 12DC
