คุณสมบัติ | รายละเอียด |
|---|---|
| Cross Sectional Area | 0.34 mm² |
| Number of Cores | 4 |
| Sheath Material | PUR |
| Sheath Colour | Black |
| Length | 2m |
| Connector 1 Orientation | Straight |
| Connector 1 Number of Contacts | 4 |
| Connector 1 | M12 |
| Connector 1 Gender | Male |
| Connector 2 | M12 |
| Connector 2 Housing Gender | Female |
| Connector 2 Gender | Female |
| Connector 2 Orientation | Right Angle |
| Connector 2 Number of Contacts | 4 |
| Shielded/Unshielded | Unshielded |
| Current Rating | 4 A |
| Voltage Rating | 30 V dc |
| IP Rating | IP65, IP66K, IP67 |
| Maximum Operating Temperature | +85°C |
| Standards Met | cLus Certified, CSA, cULus, DIN VDE 0298-4, EN 60529, IEC 60664-1, UL |
| Oil Resistant | Yes |
| Operating Temperature Range | -25 - +85 °C |
| Insulation Material | PVC |
| Conductor Material | Copper |
| Minimum Operating Temperature | -25°C |
| Cable Shape | Round |
| Connector 1 Housing Gender | Male |
| Outer Diameter | 15mm |
| American Wire Gauge | 22 AWG |
| Minimum Bend Radius | 10 x 15 mm |
7000-P4291-9800050
7000-12221-6342000
YF2A25-050UB6XLEAX
